Aluminum strip 3003

Alloy Series:3003
Temper: O
Thickness: 0.3-4.5mm, tolerance: +/-0.02mm
Width: 20-800mm, tolerance:+/-1mm
Surface: Mill Finish、Coated、Powder Coated、Anodized、Polished mirror、Embossed、Brushed

Availability:

Quantity:



Inquire Add to Basket

Aluminum strip 3003

An aluminum strip is a flat, elongated piece of aluminum that is typically characterized by its rectangular shape. These strips are cut to specific widths and thicknesses and are used in various industries for different purposes. Here are some key points about aluminum strips:

1) Aluminum strips are made from aluminum, a lightweight and corrosion-resistant metal.

2) Different aluminum alloys may be used to produce strips, each offering specific properties. Common alloys include 1xxx, 3xxx, and 5xxx series, with 3003 being a common choice for general-purpose applications.

3) Aluminum strips come in various dimensions, with thickness and width being the key parameters. The choice of dimensions depends on the specific requirements of the application.

Aluminum Strip Thin Aluminum STRIP Flat Aluminum Strip 3003 Aluminum Strip

Product					Contract No.				Lot No.
Dimension (mm)	0.2-1.6				Alloy		3003		Piece Count
Techuique Standard					GB/T3190--1996/EN				Weight(kg)
Chemical Composition(%)
	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Others		Al
Standard	0.6	0.7	0.05-0.2	1.0-1.5	-	-	-	0.1	-	0.15		Remain
Notice:Aluminum foil not contains Pb、As and other Virose elements
Mechanical Property
Temper	Thickness		Tensile Strength（Mpa）			Strength(Mpa)			Elongation%		Cup Bulge
H18	0.2-0.5		185			165			1		-
	0.51-0.8								2		-
	0.81-1.3								3		-
	1.31-1.6								4		-
H16,H26	0.2-0.3		165-205			145			1		-
	0.31-0.5								2		-
	0.51-0.8								3		-
	0.81-1.3								3		-
	1.31-1.6								4		-
H14,H24	0.2-0.3		140-180			-			1		-
	0.31-0.5					-			2		-
	0.51-0.8					-			3		-
	0.81-1.3					120			4		-
	1.31-1.6					120			5		-
H12,H22	0.2-0.3		120-155			-			2		-
	0.31-0.5					-			3		-
	0.51-0.8					-			4		-
	0.81-1.3					85			5		-
	1.31-1.6					85			6		-

Product					Contract No.				Lot No.
Dimension (mm)	0.2-1.6				Alloy		3003		Piece Count
Techuique Standard					GB/T3190--1996/EN				Weight(kg)
Chemical Composition(%)
	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Others		Al
Standard	0.6	0.7	0.05-0.2	1.0-1.5	-	-	-	0.1	-	0.15		Remain
Notice:Aluminum foil not contains Pb、As and other Virose elements
Mechanical Property
Temper	Thickness		Tensile Strength（Mpa）			Strength(Mpa)			Elongation%		Cup Bulge
H18	0.2-0.5		185			165			1		-
	0.51-0.8								2		-
	0.81-1.3								3		-
	1.31-1.6								4		-
H16,H26	0.2-0.3		165-205			145			1		-
	0.31-0.5								2		-
	0.51-0.8								3		-
	0.81-1.3								3		-
	1.31-1.6								4		-
H14,H24	0.2-0.3		140-180			-			1		-
	0.31-0.5					-			2		-
	0.51-0.8					-			3		-
	0.81-1.3					120			4		-
	1.31-1.6					120			5		-
H12,H22	0.2-0.3		120-155			-			2		-
	0.31-0.5					-			3		-
	0.51-0.8					-			4		-
	0.81-1.3					85			5		-
	1.31-1.6					85			6		-
