5mm Anti Slip Aluminum Sheet

5mm Anti Slip Aluminum Sheet
Alloy Series:1000,3000,5000
Temper: H14
Thickness: 0.6-5mm, tolerance: +/-0.02mm
Width: 1219mm, tolerance:+/-1mm
Length: 2438mm, tolerance:+/-1mm
Surface: Painted, Coated, Embossed,Mill finish,Bright finish"

Availability:

Quantity:


Inquire Add to Basket

Product Description
Product Attributes
Supply Ability
Application
Packing

Our Anti Slip Aluminum Sheet what is aluminium 5 bar tread plate is supplied in grade 1100/3003.It’s easy to clean, features good slip resistance, and also has a decorative industrial appearance. It can also be used for door kick plates, door cladding, access ramp covering for wheelchairs, and stair treads.
Pattern Type: Small Five Bar, Big Five Bar, Diamond

Anti Slip Aluminum sheet Anti slip aluminum planel 5mm Anti Slip Aluminum Sheet Aluminum Sheet Aluminum Sheet 3003

Product					Contract No.				Lot No.
Dimension (mm)	0.2-1.6				Alloy		3003		Piece Count
Techuique Standard					GB/T3190--1996/EN				Weight(kg)
Chemical Composition(%)
	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Others		Al
Standard	0.6	0.7	0.05-0.2	1.0-1.5	-	-	-	0.1	-	0.15		Remain
Notice:Aluminum foil not contains Pb、As and other Virose elements
Mechanical Property
Temper	Thickness		Tensile Strength（Mpa）			Strength(Mpa)			Elongation%		Cup Bulge
H18	0.2-0.5		185			165			1		-
	0.51-0.8								2		-
	0.81-1.3								3		-
	1.31-1.6								4		-
H16,H26	0.2-0.3		165-205			145			1		-
	0.31-0.5								2		-
	0.51-0.8								3		-
	0.81-1.3								3		-
	1.31-1.6								4		-
H14,H24	0.2-0.3		140-180			-			1		-
	0.31-0.5					-			2		-
	0.51-0.8					-			3		-
	0.81-1.3					120			4		-
	1.31-1.6					120			5		-
H12,H22	0.2-0.3		120-155			-			2		-
	0.31-0.5					-			3		-
	0.51-0.8					-			4		-
	0.81-1.3					85			5		-
	1.31-1.6					85			6		-

Product					Contract No.				Lot No.
Dimension (mm)	0.2-1.6				Alloy		3003		Piece Count
Techuique Standard					GB/T3190--1996/EN				Weight(kg)
Chemical Composition(%)
	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Others		Al
Standard	0.6	0.7	0.05-0.2	1.0-1.5	-	-	-	0.1	-	0.15		Remain
Notice:Aluminum foil not contains Pb、As and other Virose elements
Mechanical Property
Temper	Thickness		Tensile Strength（Mpa）			Strength(Mpa)			Elongation%		Cup Bulge
H18	0.2-0.5		185			165			1		-
	0.51-0.8								2		-
	0.81-1.3								3		-
	1.31-1.6								4		-
H16,H26	0.2-0.3		165-205			145			1		-
	0.31-0.5								2		-
	0.51-0.8								3		-
	0.81-1.3								3		-
	1.31-1.6								4		-
H14,H24	0.2-0.3		140-180			-			1		-
	0.31-0.5					-			2		-
	0.51-0.8					-			3		-
	0.81-1.3					120			4		-
	1.31-1.6					120			5		-
H12,H22	0.2-0.3		120-155			-			2		-
	0.31-0.5					-			3		-
	0.51-0.8					-			4		-
	0.81-1.3					85			5		-
	1.31-1.6					85			6		-
